Board Type:Breakout Board
Model Number:2097-TB1
Connector Count:8
Pinout Configuration:Industry-standard 5-pin configuration
Power Supply Voltage:12VDC ± 10%
Current Draw:Max 200mA per pin
Operating Temperature:-40°C to +85°C
Storage Temperature:-55°C to +125°C
Enclosure Type:IP67-rated waterproof housing
Dimensions:150mm x 70mm
Mounting:Surface mountable
The Microchip 2097-TB1 I/O Breakout Board offers a comprehensive solution for industrial control environments, ensuring robust performance and compatibility with various devices. Its compact design allows for easy integration into existing systems without compromising functionality.
Featuring 8 GPIO channels, this board supports versatile applications including sensor interfacing, motor control, and system monitoring, making it ideal for automation projects. With support for UART, SPI, and I2C protocols, it ensures seamless communication with a wide range of microcontrollers and other peripherals.
Engineered with precision, the 2097-TB1 utilizes high-quality materials for superior durability and reliability under harsh industrial conditions. Its temperature range from -40°C to +85°C ensures operation across various environments, enhancing its adaptability.
The board’s SMD mounting type facilitates efficient assembly on printed circuit boards, simplifying the manufacturing process while maintaining high performance standards. Its industry-standard pinout ensures compatibility with existing designs and facilitates quick prototyping and development.
To ensure ease of use, the Microchip 2097-TB1 I/O Breakout Board comes with detailed documentation and support resources, guiding users through setup, configuration, and troubleshooting. This commitment to customer support underscores our dedication to providing solutions that not only meet but exceed expectations in industrial control applications.
