Schneider BMXDDM16022 Discrete Mixed I/O Module

In stock

The Schneider BMXDDM16022 Discrete Mixed I/O Module is a versatile component designed for industrial automation systems, offering 8 input channels and 24VDC sink logic, along with 24VDC output channels. This module supports both digital input and output functionalities, making it ideal for various control applications.

Extended Product Type:IO Module

Product ID:BMXDDM16022H

Schneider Type Designation:Discrete Mixed I/O

Main Function:Control and monitoring of discrete signals in industrial environments

Functions:Digital Input/Output, Signal Conditioning

Supply Voltage:(DC) 24 V

Current Consumption:0.1 A at 3.3Vdc; <= 67 mA at 24 V DC

Power Dissipation:<= 3.7 W

Input Channel Count:16

Output Channel Count:16

Discrete Input Voltage:24 V DC

Positive Discrete Output Voltage:24 V 19…30 V DC

Product Weight:0.115 kg

Resistance to Harsh Environment:Conformal coated PCB

Application Scope:Automotive, Manufacturing, Packaging, Process Control

Discover the robust Schneider Electric BMXDDM16022 discrete mixed I/O module, specifically engineered for seamless integration into industrial automation systems. This module boasts an impressive array of features, including 8 digital inputs and 8 solid state outputs, ensuring efficient data processing and control functions.

Designed with a conformal coated PCB for enhanced durability and resistance against harsh environments, this module is a reliable choice for applications requiring high performance under challenging conditions. The compact yet powerful design allows for easy installation and integration into existing systems.

With its compatibility with the Modicon M340 X80 series, the BMXDDM16022 seamlessly integrates into Schneider’s comprehensive line of automation products, offering seamless connectivity and enhanced system performance.

Featuring a supply voltage of 24V DC, this module ensures stable operation across a wide range of industrial settings. Its low current consumption ensures energy efficiency, contributing to reduced operational costs without compromising on functionality.

Whether you’re looking to enhance the capabilities of your existing automation system or are planning a new project, the Schneider Electric BMXDDM16022 discrete mixed I/O module offers a cost-effective and reliable solution that meets the stringent requirements of modern industrial environments.

Schneider BMXDDM16022 discrete mixed IO module
