Pro-face PFXSP5700TPD 15" Premium Display Module, High-Tech Industrial HMI

Pro-face PFXSP5700TPD 15″ Premium Display Module, High-Tech Industrial HMI

In stock

The PFXSP5700TPD is a high-performance Human-Machine Interface (HMI) designed for industrial automation environments. It features a large 15-inch TFT color LCD screen with auto-scaling brightness sensor, offering 16 million colors and high resolution for clear visualization of complex data. This premium display module enhances operational efficiency and maintenance ease.

Manufacturer:Pro-face

Series:SP5000

Part Number:PFXSP5700TPD

Model:SP-5700TP

Backlight:White LED

Colors:16 million colors

LCD Type:TFT

Screen Size:15 Inches

Resolution:1,024 x 768 pixels (XGA)

USB Ports:1x USB (Type A), 1x USB (mini B)

Touch Features:Multi-touch

Input Voltage:12-24VDC

Enclosure Type:IP65F, IP67F

Dimensions:W397 x H296 x D67mm (W15.6 x H11.7 x D2.64 in.)

Weight:Not specified

The PFXSP5700TPD, also known as SP-5700TP, is a premium display monitor from Pro-face, designed to be a part of the modular SP5000 series. It is tailored specifically for industrial control systems where high-quality visualization is essential.

This 15-inch display module utilizes a TFT-type color LCD screen that ensures vivid and accurate color reproduction, with a resolution of 1,024 x 768 pixels, providing users with crystal-clear images.

Featuring an auto-scaling brightness sensor, the display automatically adjusts its luminosity based on ambient light conditions, ensuring optimal visibility and energy efficiency.

With its robust IP65F and IP67F enclosure rating, the PFXSP5700TPD is built to withstand harsh industrial environments, protecting against dust, water, and mechanical impacts.

Designed for ease of use, the PFXSP5700TPD includes multiple connectivity options including USB ports and supports multi-touch functionality, enhancing user interaction with industrial control software.
