Model:KT-16T
Manufacturer:KEYENCE
Type:Small PLC
Input Ports:Screw Inputs at Bottom
Output Ports:Positioned Below Input Ports
Programming Interface:Windows Ladder Software Compatible
Clock Output Pulse:20 kHz
Impulse Response Time:25us
LED Indicators:15 Numbered LEDs on Front
Power Connector:Power Connector Cable at Underside
Mounting Options:Metal Hanging Brackets on Underside
Dimensions:Very Small and Compact
The KEYENCE KT-16T is a small programmable logic controller (PLC) designed to provide exceptional space-saving performance in industrial environments. Its compact design makes it perfect for applications where space is limited. The PLC features screw inputs at the bottom of the unit, allowing for secure and reliable connections.
The right side of the PLC features an ‘IN’ port positioned toward the top of the device, with the ‘OUT’ port directly below it. The KT-16T also includes a series of numbers at the top of the unit ranging from C000-009, indicating the controller’s various functions and operations. Additionally, there is a small flap on the right-hand side labeled ‘pull,’ which reveals an Ethernet port for convenient connectivity.
On the front of the unit, you’ll find 15 numbered LED lights to indicate input/output status. The bottom front of the unit has the word ‘out’ to indicate output, along with a sequence of numbers ranging from C3-8 9 10-11 C4-12 13 14-15. The underside of the unit features a power connector cable and 11 wire connections, surrounded by venting to maintain proper operating temperatures in higher temperature conditions.
For installation, the unit can be panel-mounted using the two metal hanging brackets located underneath. This model also features small vents under the top ports to allow for proper airflow, ensuring the PLC operates at its best.
Cleaning these vents clear of dust, hair, dirt, and debris is crucial to maintaining optimal performance. The KT-16T is compatible with Windows Ladder software, enabling precise positioning at varying speeds with a real-time read. This model, like others in the KT Series, can receive an impulse as short as 25us at any time in the program.
