Honeywell EG1033AA EG1033AA01 Flame Detector

Product Overview

Model Description: Honeywell EG1033AA EG1033AA01 flame detector belongs to Honeywell products, which EG1033AA01 is the specific model of the product, it is a UV flame detector.

Application: Mainly used in gas turbines and other large combustion equipment flame monitoring system, hydrocarbon flame can be produced by the detection of ultraviolet radiation, to provide protection for the safe operation of the equipment, to ensure that the combustion process can be timely and accurate detection of the flame state.

Performance characteristics

High sensitivity: it can respond quickly to the appearance of flames, with a typical flame appearance response time of 0.1 seconds, and can detect weak flame signals in a short period of time, which effectively improves the timeliness and accuracy of flame monitoring.

Good anti-interference ability: daylight, lightning, welding, artificial light, ambient thermal radiation, electromagnetic interference, mechanical vibration and other interference has a very good inhibition, can work stably in complex environments, to avoid false alarms, to protect the reliability of the system 1.

Wide operating temperature range: the operating temperature range of – 40 ℃ to 176 ℃, can adapt to a variety of harsh industrial environments, whether it is a high-temperature combustion site or low-temperature outdoor environments, can operate normally.

Multiple Outputs: Hardware outputs include transistor open collector outputs (EG1033AA) as well as relay contact outputs (EG1033AB and EG1033AC), which can meet the needs of different users and facilitate the connection with various control systems.

Long-range monitoring: The sensor-to-amplifier operating distance of up to 330 metres (1,000 ft) enables monitoring of a wide range of flames, making it suitable for large combustion plants and complex industrial scenarios.

Technical Specifications

Power supply voltage: the amplifier module’s power supply voltage is 24-28V DC, in addition to support for 28V DC, 20-35V DC and 115V AC and other voltage requirements, according to the actual application scenarios to choose the appropriate power supply.

Detection wavelength range: It can detect light in the wavelength range of UV radiation between 180-260nm, which can effectively avoid the interference of natural light sources and accurately identify flame signals.

Reliability indicators: with a two-year warranty and more than 10,000 hours of Mean Time Between Failure (MTBF), and has more than 35 years of reliable operation experience on General Electric gas turbines, proving its stability and reliability in long-term operation.

Certifications
