Operating Voltage (V):12 – 48VDC
Current Rating (A):1.5 – 5A
Stepper Motor Compatibility:Step and Direction Signals
PWM Frequency (kHz):0 – 2000
Communication Interface:RS485, Modbus RTU
Input Resolution:1/16 Step
Operating Temperature (°C):-20°C to +70°C
Protection Class:IP20
Engineered for exceptional performance, the Hanmark SD2202 Stepper Motor Driver is a cornerstone in the realm of industrial automation. Its advanced digital control system ensures unparalleled precision and reliability, making it an ideal choice for demanding applications.
Featuring a robust design, this driver is capable of handling loads up to 1000 oz-in, providing a versatile solution for a wide array of mechanical systems. Its compatibility with a broad voltage range from 12V to 48V DC ensures flexibility across different operational environments.
Operating within a temperature range of -20°C to 70°C, the SD2202 maintains consistent performance regardless of environmental conditions. This durability is complemented by its high current consumption capability of 1.5A max, allowing for efficient power delivery to the stepper motor.
With support for up to 20kHz PWM frequency, the driver ensures smooth operation and precise control over the motor’s speed and torque. Its stepping modes, including 1/4, 1/8, 1/16, and full steps, offer customization for various applications, ensuring optimal performance.
The SD2202’s driver type, a half-bridge H-bridge, provides a reliable and cost-effective solution for driving stepper motors. Coupled with its RS-485 communication interface, this driver facilitates seamless integration into complex control systems, enhancing the overall efficiency of automation projects.
