Display Size:40 characters
Windings Per Phase:Two
Current Input Windings:3 phases with 5 amps
Input Outputs:Analog
Protection Features:Overexcitation, Transformer Overload, Frequency Rate-of-Change Detection
Case Dimensions:Height: 9 inches, Width: 7 inches, Depth: 7.125 inches
Mounting Options:Standard 19” Panel Mountable
The GE 745-W2-P5-G5-LO-A-L-R-E provides an essential layer of protection for transformers, autotransformers, and reactors. Its innovative design features an enhanced 40-character display for improved readability and a user-friendly keypad for easy setpoint adjustments. With a compact footprint of 9 x 7 x 7.125 inches, it offers a space-saving solution that can be easily installed on a standard 19-inch panel.
This protection system utilizes adaptive features such as Dynamic CT Ratio Mismatch Correction, Overexcitation Protection, and Transformer Overload Protection to enhance overall system reliability and longevity. Real-time alerts through LED indicators keep operators informed about operational statuses and potential faults. The unit’s capabilities for monitoring hotspots further aid in preemptive maintenance, ensuring minimal downtime and maximum efficiency.
For installation, care must be taken to ensure adequate clearance for the unit’s door to avoid any interference with other components. Its comprehensive monitoring features make it an indispensable tool for engineers and technicians working in high-stakes industrial environments where transformer health directly impacts operational continuity.
