Voltage Range:90 to 300 VDC; 70 to 265 VAC at 48 to 62 Hz
Number of Woundings:Three per phase
Control Power:Higher
Input/Output Options:Analog, Loss of Life, Restricted Ground Fault
Processor Type:Multi-processor
Display:Enhanced LCD
Monitoring Features:Hottest Spot Monitoring, Dynamic CT Ratio Mismatch Correction, Overexcitation Protection, Transformer Overload Protection, Frequency Rate-of-Change Detection
Metering Capabilities:Integrated for streamlined operation
Compatibility:Part of the GE Multilin/745 Transformer Protection System
The GE 745-W2-P5-G5-HI-A-L-R Relay is a multi-processor system featuring adaptive capabilities for real-time response to system events, enhancing safety and operational efficiency.
With its advanced LCD display, this relay provides clear and comprehensive information about transformer conditions, enabling proactive maintenance and immediate corrective actions.
Equipped with a wide range of protection features, including dynamic CT ratio mismatch correction, this relay safeguards against overexcitation, overload, and frequency rate-of-change anomalies, extending the life of transformer elements and reducing downtime.
The inclusion of analog input/output functionality allows for flexible integration with other monitoring systems, while the optional general-purpose transducer input supports custom monitoring parameters tailored to specific applications.
Designed for rugged industrial environments, the GE 745-W2-P5-G5-HI-A-L-R Relay operates reliably within a broad temperature range, ensuring continuous performance even under extreme conditions.
