Manufacturer:ABB
Model Number:CI590
Submodel:CS31-HA
Input Channels:8 Digital Inputs, 4 Analog Inputs
Analog Input Range:0-10V, ±10V, 0-20mA, 4-20mA
Digital Input Voltage:24V DC
Current Output:24V DC, 0.5A
Analog Input Resolution:12-bit + Sign
Communication Interface:CS31 or CI5xx
Operating Voltage:24V DC
Process Power Supply:24V DC
Isolation:Channel-to-Channel Isolation
Weight:0.200 kg
Package Contents:1 Module, Installation Guide
This ABB CI590-CS31-HA Mixed Analog/Digital I/O Module is an integral component in industrial control systems, delivering exceptional performance and reliability.
The module features eight digital input channels with 24 V DC power supply, capable of configurable filtering times ranging from 0.1 ms to 32 ms. These digital inputs can be utilized in conjunction with the AC500CPU for high-speed counting up to 50 kHz.
It also includes four independent analog input channels, supporting voltage (0…10V, ±10 V) and current (0/4…20 mA) signals. Each channel is equipped with 12-bit resolution and can be configured individually.
For output, the module provides eight channels with 24 V DC power supply, each capable of handling up to 0.5 A. It supports analog outputs with 12-bit resolution, enabling precise control over analog signals.
The module is designed with channel-to-channel isolation, ensuring robust performance even in demanding environments. Its compact design and reliable operation make it a perfect fit for a wide range of industrial applications.
