Series:PowerFlex 525
Brand:Allen-Bradley
Module Type:Terminal Base
Output Current:27 A
Input Voltage:323-528 VAC
Input Phase:3-Phase
Input Current:31.6 A
Output Voltage:0-460VAC
Rated Power:18.5kW (25Hp)
Voltage:Three Phase, 480 VAC
Enclosure Rating:IP20 / NEMA UL Open Type
Installation:Panel Mount
Control Method:Volts / Hertz Control; Sensorless Vector Control
Integrated Safety:Safe-Torque Off (STO) functionality
Communication Protocols:Optional: ProfiBus, Ethernet, DeviceNet
Built-in Communication Port:RS485; Ethernet
Discrete Inputs:Seven (7)
Discrete Outputs:Two (2) Opto Outputs and Two (2) Relay Outputs
Analog Input:Two (2)
Analog Output:One (1)
The A-B 25B-E027N104 PowerFlex 525 is designed for industrial environments where precise motor control is critical. Featuring a terminal base output current of 27A, this drive is capable of handling a wide range of industrial applications with ease. It supports three-phase input voltage ranging from 323 to 528 VAC, providing reliable power supply to motors under varying load conditions. Its advanced safety features, such as Safe-Torque Off (STO), ensure operator safety and prevent unintended motor start-up.
This AC Drive is built with an IP20/NEMA UL open type enclosure, offering protection against dust and water splashes, making it suitable for both indoor and outdoor installations. With optional communication protocols like ProfiBus, Ethernet, and DeviceNet, this drive can be easily integrated into existing industrial networks for seamless communication.
For installation, the A-B 25B-E027N104 PowerFlex 525 can be mounted on panels, ensuring easy access for maintenance and integration with other components. The drive comes with two discrete outputs and seven inputs, providing flexibility in controlling various devices and sensors within an automated system.
