Model Type:Analog Input Module
Manufacturer:Allen Bradley
Product Number:1746-INT4
Channels:4 (Input)
Common Mode Voltage Range:-20 To 20 V
Absolute Input Voltage:Plus/Minus 7.5 VDC Or 7.5 VAC RMS (Maximum)
Input Range:-10 To 10 VDC – 1 LSB
Absolute Input Current:-30 To 30 MA (Maximum)
Voltage Rating:Overvoltage Protection: 7.5 VAC RMS
Current Rating:Backplane Current Draw: 35 MA At 5 V, 85 MA At 24 V
Isolation:Backplane: 500 VDC, Enclosure: Open Type
Operating Temperature:-40 To 70 °C
Power Consumption:1.5 W (Typical)
Mounting Type:Panel Mount
Dimensions:121 x 106 x 96 mm
Weight:0.6 kg
The AB 1746-INT4 Analog Input Module from AB (Allen-Bradley) is a robust and versatile addition to any industrial automation system, offering precise analog signal acquisition capabilities.
Engineered with advanced technology, this module ensures reliable data collection from sensors and other measuring devices, facilitating accurate process monitoring and control.
With its high-resolution input channels, the AB 1746-INT4 can handle a wide range of voltage and current inputs, making it suitable for diverse industrial applications, from temperature measurement to flow rate monitoring.
Featuring exceptional isolation and robust isolation capabilities, the module provides effective protection against electrical noise and ensures stable operation in harsh environments.
Designed for ease of integration, the AB 1746-INT4 is compatible with multiple control networks, including ControlNet, DeviceNet, and Universal Remote I/O links, enhancing its flexibility and scalability within complex systems.
Backed by AB’s commitment to quality and reliability, this Analog Input Module is meticulously crafted for long-term performance, ensuring minimal downtime and maximizing productivity in manufacturing operations.
