Product Type:Measurement Card
ABB Type Designation:SDCS-PIN-51
Dimensions:18.5 cm x 15 cm x 2 cm
Weight:0.16 kg
Operating Voltage:12 VDC
Current Rating:20 mA
Temperature Range:-20°C to +55°C
Communication Interface:RS-485
Number of Channels:8
Data Transmission Speed:1 Mbps
Certification:CE, UL, CSA
The ABB 3ADT220090R0006 SDCS-PIN-51 Measurement Card is engineered to provide unparalleled accuracy and reliability in measuring electrical parameters within industrial processes. Its robust design ensures seamless integration into various automation systems, supporting diverse applications from process control to monitoring complex machinery operations.
Equipped with advanced signal processing capabilities, this card delivers highly precise readings with an exceptional accuracy of ±0.1% Full Scale (FS), making it suitable for applications requiring high precision measurements. The card’s resolution of 0.1 μΩ allows for detailed analysis of electrical characteristics, enhancing system efficiency and performance.
Designed for a wide range of operating temperatures (-25°C to 60°C), the SDCS-PIN-51 Measurement Card ensures continuous operation under varying environmental conditions, making it ideal for industrial settings where reliability and durability are paramount.
With an input voltage tolerance of DC 24V and a current consumption of ≤20mA, this card is energy-efficient, optimizing power usage and reducing operational costs. The ability to output a 4-20mA signal makes it compatible with a broad range of industrial devices and control systems, facilitating easy integration and data transmission.
Featuring a compact size (125mm x 100mm x 30mm) and lightweight (0.2kg), the SDCS-PIN-51 Measurement Card is designed for ease of installation and maintenance. Its RS-485 connection type supports long-distance data communication, ensuring reliable data transfer even over extended distances.
