ABB PDB-02 | 3HNA026293-001 | Thermocouple/mV Input Module

In stock

The ABB PDB-02 3HNA026293-001 Thermocouple/mV Input Module is designed for precise temperature data acquisition in industrial automation systems. This module seamlessly integrates with various temperature sensors and converts their outputs into a standard mV signal, facilitating accurate monitoring and control in diverse industrial applications.

Type:Thermocouple/mV Input Module

Model:3HNA026293-001

Brand:ABB

Module Designation:PDB-02

Number of Channels:16

Input Range:-200°C to +1600°C / 0mV to 100mV

Accuracy:±0.2% F.S.

Sampling Rate:Up to 500 Hz

Power Consumption:≤ 2W

Operating Temperature:-20°C to +70°C

Storage Temperature:-40°C to +85°C

Dimensions (DxHxW):90mm x 100mm x 35mm

Weight:100g

The ABB PDB-02 Thermocouple/mV Input Module 3HNA026293-001 is engineered to provide unparalleled precision in temperature and voltage measurement within industrial automation systems. Its robust design ensures reliable performance under a wide range of operating conditions, making it an ideal choice for applications requiring high accuracy and stability.

Equipped with advanced signal processing technology, this module accurately converts thermocouple signals and millivolt readings into digital values, facilitating seamless integration into PLC systems for efficient data acquisition and control operations.

Featuring a compact size and durable construction, the module is easy to install and maintain, offering a streamlined solution for integrating temperature and voltage monitoring capabilities into existing control networks. It supports various thermocouple types (K, J, E, T, etc.) and is compatible with industry-standard power supplies, ensuring compatibility and ease of use.

Designed for long-term reliability, the ABB PDB-02 Thermocouple/mV Input Module 3HNA026293-001 is built to withstand harsh industrial environments, withstanding extreme temperatures and humidity without compromising performance. Its low current consumption ensures minimal power draw, reducing operational costs.

To further enhance user convenience, the module includes intuitive diagnostic LEDs and error codes for quick identification of issues, enabling rapid troubleshooting and maintenance. Comprehensive documentation and technical support are provided to ensure a smooth setup and operation experience.

ABB PDB-02 3HNA026293-001 Thermocouple/mV Input Module
