Output Current:45 Amperes
Nom Drive Voltage:360-480 Volts (3 Phase)
Wattage:22 kWatts
Dimensions:7.7 x 11.9 x 16.7 inches (196 x 302 x 426 mm)
Weight:22.0 lbs (9.98 kg)
Input Voltage Range:324-528V RMS, 3-phase
Input Frequency:47-63 Hz
Main AC Input Current:71.0 Ampere nominal
DC Input Voltage for Common Bus Follower:458-747V DC
Operating Temperature:0…50 °C (32…122 °F)
Relative Humidity:5…95% noncondensing
Operating Altitude:Up to 3281 ft (1000 m) without derating, up to 9843 ft (3000 m) with derating
Vibration Rating:5…55 Hz @ 0.35 mm (0.014 in.) double amplitude
Safety Feature:Safe Torque-off
Series Availability:Three series, A with standard overload support, B and C with Standard or Peak Enhanced options
Crafted with precision for optimal performance in harsh industrial environments, the Siemens 2094-BC07-M05-M Integrated Axis Module is an essential component for modern automation lines. Its compact design ensures efficient space utilization without compromising on functionality.
Equipped with state-of-the-art technology, this module supports a wide range of communication protocols, enabling seamless integration with various control systems and ensuring smooth data exchange. It is compatible with advanced encoders, providing precise feedback for accurate motion control.
With an operating voltage of 24 V DC, this module is designed to withstand fluctuating power conditions typically encountered in industrial settings. Its robust construction allows for reliable operation within a broad temperature range from -25°C to +60°C, making it suitable for diverse applications.
Featuring a Profinet interface, the Siemens 2094-BC07-M05-M offers high-speed data transfer rates, significantly improving the responsiveness and efficiency of control systems. This interface facilitates direct communication between the module and other devices in the network, streamlining system integration and maintenance.
In addition to its technical capabilities, the module is manufactured using high-quality materials to ensure durability and longevity. It comes with detailed installation guidelines and support documentation, simplifying the setup process for users and minimizing downtime during installation.
