Brand:Allen-Bradley
Model:442L-PA40430CBCD
Type:Safety Light Curtain
Primary Housing Material:Aluminum
Connector Type:M12 Pigtail
Dimensions:WxDxH (mm): 28 x 26 x 110
Number of Pins:8
Operating Voltage:24 V dc +/- 15%
OSSD Rating:24 V dc at 0.5 A each
Supply Current:210 mA max.
Safety Outputs:2 Independently Controlled Safe Outputs
Output Configuration:2 sets of 2 NO
Power Consumption:0.15 A (outputs on)
Certifications:CE, UL, ISO 13849-1
The Allen-Bradley 442L-PA40430CBCD SafeShield SafeZone Safety Light Curtain is designed for applications requiring high levels of safety. Its robust aluminum housing ensures durability in harsh industrial environments. Featuring an M12 connector, this light curtain is easy to install and maintain. With a detection range of up to 6 meters, it provides comprehensive coverage for various machinery and equipment. The safety light curtain operates on a 24 V dc supply, drawing a maximum current of 140 mA, making it energy-efficient. Equipped with an OSSD rating of 24 V dc at 0.5 A, it ensures reliable performance even under demanding conditions. Compliant with IP67 standards, this safety light curtain is dust-tight and can withstand temporary water immersion, making it suitable for outdoor use. The system is built with reliability and safety in mind, offering peace of mind for operators and facility managers.
